Products / Power transformers

TSL(Z) 250-2500/10(6) N3, NF3, T3

Three-phase dry-type transformers with cast insulation
TSL 400/10(6) N3
TSL 400/10(6) N3
TSLZ 1000/10(6)
Equipment request
Models for delivery:
TSL 250/10(6) N3
TSLZ 250/10(6) N3
TSL 400/10(6) N3
TSLZ 400/10(6) N3
TSL 630/10(6) N3
TSLZ 630/10(6) N3
TSL 1000/10(6) N3
TSLZ 1000/10(6) N3
TSL 1250/10(6) N3
TSLZ 1250/10(6) N3
TSL 2500/10(6) N3
TSLZ 2500/10(6) N3
Producer
"KTZ" JSC
[X][X][X]
Description


1. General characteristics:

Power range
250-2500 kVA
Winding connection
D/Yn-11, Y/Yn-0
Voltage HV winding
6, 10 kV
Voltage LV winding
0,4 kV
Unprotected execution (type TSL)
degree of protection IР-00
Protected execution (type TSLZ)
degree of protection IР-21
Non-excitation regulating power
±5×2,5%.


2. Assignment:

Three-phase dry-type transformers with cast insulationwith non-excitation regulating. Designed to convert electrical energy into electric three-phase alternating current with frequency of 50 Hz. Installed in industrial premises and public buildings, which have high requirements in terms of fire safety, explosion-proof, pollution-free.

Transformers are available in the version with degree of protection IP00 (without casing — type TSL) or IР21 (with casing — type TSLZ). Against overheating transformers protected thermal protection posistor, built-in winding of the low voltage and displayed on the terminals of the thermal switch. The voltage regulation of ±5% in steps of 2.5% non-excitation regulating power by moving jumpers.


3. Conditions:

Height over sea level
up to 1000 m
Temperature for temperate climates
from −60°C to +40°C
Thermal class
F
Thermal class of winding
Н
Fire class
F1


4. Working resource:

Operating mode
long
Warranty period
3 years
Full life
not less than 25 years


5. Construction of transformers:

The active part consists of a magnetic core made of cold-rolled electrical steel coils and switch. A special form of execution of the magnetic circuit allows you to create a connection called «STEP-LAP», which proved to be excellent low noise and low no-load losses. The finished magnetic core is covered with two-component coating for corrosion protection.

In the protected execution transformer housing made of steel sheet. After installation of the transformer hanging nuts dismantled.




1. Savings during installation:

Simple and inexpensive preparatory installation work. The compact size of the units.


2. Energy saving:

Reduction of losses in the lines of electricity and the cost of the cable in low voltage networks due to the close placement of the transformer to the electricity consumers. Savings in the transformer due to the low losses in the magnetic core and the windings.


3. Easy maintenance:

Transformers insulated with molded resin designed for use in severe climatic and environmental conditions, so preventive maintenance is reduced to a simple examination and verification of connections and sensors.


4. Maximum safety:

High resistance of transformers to spontaneous combustion and low emission of toxic gases as for the class F0, and for class F1. Natural cooling is carried out by atmospheric air, not fire and polluting liquids. The absence of the possibility of overheating of the transformer. Measurement and control of temperature using the thermal controllers and temperature sensors. The sensors also help to control the fan transformer.


5. Modernization performance:

Low noise level. The ability to withstand overloads. The short-term increase in load power (overload) up to 40% through the use of forced ventilation.


6. High reliability:

The absence of partial discharge. Increased reliability due to the high technological production process of the windings.




1. Capacity from 250 to 2500 kVA:

ModelIdling losses, WShort circuit losses, WVoltage short circuit, %
TSL(Z)-25070027504.0
TSL(Z)-400115043004.0
TSL(Z)-630145061006.0
TSL(Z)-1000180098006.0
TSL(Z)-16002750135006.0
TSL(Z)-25003840182006.0


Winding connection:

Capacity from 250 to 1000 kVA
D/Yn-11, Y/Yn-0
Capacity from 1600 to 2500 kVA
D/Yn-11




1. TSL type. Without casing. Capacity from 250 to 2500 kVA:

PowerHBLMOhh1h2cIbWeight
250 kVA11707301430425930---5505501210 kg
400 kVA144085015604601025---6706701710 kg
630 kVA146085017305351005---6706702164 kg
1000 kVA1675100018405701215---8208202895 kg
1600 kVA2030100019306051535---8208204065 kg
2500 kVA2280125020801755000---107010705610 kg


2. TSLZ type. With casing. Capacity from 250 to 2500 kVA:

PowerHBLMOhh1h2cIbWeight
250 kVA16008601770425-132013101005505501480 kg
400 kVA16709801820460-146014801006706702025 kg
630 kVA17259801990535-151515151006706702510 kg
1000 kVA196510142095570-175017501208208203290 kg
1600 kVA235011152265605-209020901308208204490 kg
2500 kVA261012642255665-22902085150107010706110 kg



Download
pdf
Transformers TSLZ 6(10) kV (200,8 KB)
technical details
