TDNS 10000-16000/35 N1

Three-phase double-winding oil transformers
Transformer TDNS 10000-16000/35 N1
Equipment request
Models for delivery:
TDNS-10000/35 N1
TDNS-16000/35 N1
Producer
"KTZ" JSC
[X][X][X]
Description


1. General characteristics:

Power range
10000, 16000 kVA
Winding connection
Yn/D-11
Voltage HV winding
36,75
Voltage LV winding
10,5; 6,3 kV
Voltage regulation
On-load regulating power HV ±8×1,5%


2. Assignment:

Three-phase double-winding oil transformers, with natural oil cooling, with on-load regulating power. Automatic control produced from the controller supplied by the transformer. Designed to work in systems of power transmission over long distances, while providing a minimum electrical losses in power lines. The use of a transformer TDNS type allows to provide the consumer with a reliable power supply during the entire period of operation.


3. Conditions:

Height over sea level
up to 1000 m
Temperature for temperate climates
from −45°С to +40°С
Relative humidity
no more than 80% when +25°C


4. Working resource:

Operating mode
long
Warranty period
3 years
Full life
not less than 25 years




1. Capacity from 10000 to 16000 kVA:

ModelWinding connectionIdling losses, kWtLoss short circuit, kWtShort-circuit voltage, %Idling current, %
TDNS-10000/35Yn/D-118,5608,00,3
TDNS-16000/35Yn/D-111385100,3




1. Capacity from 10000 to 16000 kVA:





PowerLBHH1H2H3ANKhh1
10000 kVA427029004420255772044515241000260350365
16000 кВА468029004725287272069015241000260355390
PowerFull weight, kgTransport weight, kgOil, kg
10000 kVA20500175007500
16000 kVA28500240007800



Download
pdf
Transformers TDNS 35 kV (137,2 KB)
